DVP SX3 series
To fulfill the market demands for value-added, compact versatile programmable logic controllers, Delta’s third generation DVP PLCs SX3 series employs the AS series PLC’s 32-bit high-speed processor and provides a user-friendly programming interface, built-in analogues, multiple communication ports, and expanded program capacity. Compared with the second generation, the SX3 series upgrades execution speed, program capacity, information security, and interoperability.
Features & Benefits:
- Faster Execution Speed: 25 ns for basic instructions (with the AS Series PLC processor)
- Larger Program Capacity: 64K steps
- Max I/O: 512 points (256 inputs + 256 outputs), including its built-in 16 inputs and 16 outputs, with expansion on both sides up to 8 modules per side
- New Programming Software: DIADesigner enhances security and system integration
- Communication Ports: Built-in RS-485 ports (2), analog I/O, and Micro SD card interface
- Protocol Support: EtherNet/IP (Scanner/Adapter), Modbus TCP, CANopen DS301
Applications:
- Positioning control
- Material cutting machines (high-speed servo control)
- Crane main hoists
- Material clips controlled by servos
- Optoelectronics equipment
- Semiconductors
- Textiles
- HVAC
Specifications:
- Software: DIADesigner
- Execution Speed: 25 ns (AS core)
- Program Capacity: 64K steps
- Built-in Features: 24VDC powered CPU module, Ethernet port x 1, RS-485 ports x 2, USB port x 1, CAN port x 1, Micro SD interface x 1, 20 I/O, removable terminal blocks
- Protocols and Max. Axes: CANOpen DS301 (controls up to 64 slaves), Delta mode: controls 8 Delta servos and 8 Delta motor drives
- Max. I/O Points: 512 points (256 inputs + 256 outputs), with expansion up to 8 modules per side
- Built-in I/O Points: 20: 8DI + 6DO + 2AO + 4AI
